Waterjet Cutting Machine for glass, metal, stone and rubber, plastic, etc.
Product Description
Application and advantages of waterjet cutting:
Waterjet Cutting Machine is an effective tool for any shape of artistic creation. The traditional cutting method is saw
cutting only in a row. When cutting the curves, the model should be made according to the size and then polished. Waterjet Cutting Machine can cut any shape of models under the control of the CNC program.
1. Smooth cutting quality is perfect.
2.The cutting accuracy of waterjet cutter is up to 0.1mm. Edge joints are regular, and water jet cutting can also make very complex puzzles and murals.
3. Cutting speed is fast, and product consistency and interchangeability are very good.
4. Drilling, cutting and forming can be done at once.
5. Improve the working environment and reduce the impact of dust and noise on the operator.
6. Waterjet cutting is a cold cutting that does not damage the internal structure of the material.
7. It is the only machine for processing composite materials and fragile porcelain.
8. Waterjet Cutter can cut metal, rubber, foam, plastic, composite materials, stone, ceramic tile, marble, glass, etc.
cutting only in a row. When cutting the curves, the model should be made according to the size and then polished. Waterjet Cutting Machine can cut any shape of models under the control of the CNC program.
1. Smooth cutting quality is perfect.
2.The cutting accuracy of waterjet cutter is up to 0.1mm. Edge joints are regular, and water jet cutting can also make very complex puzzles and murals.
3. Cutting speed is fast, and product consistency and interchangeability are very good.
4. Drilling, cutting and forming can be done at once.
5. Improve the working environment and reduce the impact of dust and noise on the operator.
6. Waterjet cutting is a cold cutting that does not damage the internal structure of the material.
7. It is the only machine for processing composite materials and fragile porcelain.
8. Waterjet Cutter can cut metal, rubber, foam, plastic, composite materials, stone, ceramic tile, marble, glass, etc.
Product Advantages:
1.Cutting accuracy is up to 0.1mm.
2.The main core components of Intensifier is made in USA”.
3.The guide screw with oil-immersed structure different from the traditional dry structure. The linear guide rail and ball screw are immersed in the oil tank ,which can fully lubricate the guide screw and further isolate the water and abrasive,so as to maintain the cutting accuracy.
4.The high-power servo motor and the guide screw are connected directly by flexible coupling, which eliminates the gap of traditional belt connection and improves the cutting precision.
1.Cutting accuracy is up to 0.1mm.
2.The main core components of Intensifier is made in USA”.
3.The guide screw with oil-immersed structure different from the traditional dry structure. The linear guide rail and ball screw are immersed in the oil tank ,which can fully lubricate the guide screw and further isolate the water and abrasive,so as to maintain the cutting accuracy.
4.The high-power servo motor and the guide screw are connected directly by flexible coupling, which eliminates the gap of traditional belt connection and improves the cutting precision.
High pressure system specifications | |||||
Model | WL30018Z | WL38030Z | WL42037Z | ||
Max. Pressure | 300Mpa | 380Mpa | 420Mpa | ||
Continuous working pressure | 260Mpa | 340Mpa | 380Mpa | ||
Power | 18KW | 30KW | 37KW | ||
Maximum water flow | 3.7L/min | 3.7L/min | 3.7L/min | ||
Maximum nozzle diameter | 0.33mm | 0.33mm | 0.33mm | ||
Working power supply | 380V/50HZ | ||||
Technical parameters of gantry cutting platform | ||||||
Model | WL2015BA | WL2030BA | WL3020BA | WL2040BA | WL2060BA | WL3060BA |
X axis | 2000mm | 2000mm | 3000mm | 2000mm | 2000mm | 3000mm |
Y axis | 1500mm | 3000mm | 2000mm | 4000mm | 6000mm | 6000mm |
Z axis | 150mm | 150mm | 150mm | 150mm | 150mm | 150mm |
Running speed | 9000mm/min | |||||
Cutting accuracy | ±0.1mm | |||||
control precision | ±0.01mm | |||||
Repeat accuracy | ±0.05mm | |||||
Description of five-axis :
The AB 5-axis water jet cutter is a solution for small angle bevel cutting in stone industry and metal high-precision vertical cutting. The cross structure of the two axis is sensitive in response and fast in motion. It can realize plane 3D cutting less than 8°, and all of the path programming and angle change are completed intelligently and automatically which is convenient and quick and has a very high cost performance ratio.
The AC five-axis water jet cutter is a professional solution for large angle bevel cutting, continuous change of cutting angle and high precision cutting. The larger thermal stiffness structure and precise transmission system make the dynamic error less than or equal to plus or minus 0.05mm. With automatic programming and intelligent dynamic differential compensation, more complex plane 3D cutting can be achieved.
Why Choose Us
Company Profile
Certification and Samples
Service
Packing and Delivery
Delivery Time | 30days |
Payment Term | T/T,30% in advance ,70% before shipment(negotiable) |
Packaging details | Normal packaging is container. We can also according to the special requirements of customers for packaging |
port | Dalian |
Validity | 45 days from the date we offered validity |
FAQ
Q: What is the advantage of water jet cutting machine?
A :Cold processing, no heat reaction zone. no deformation; strong cutting ability, pure water jet can cut soft materials, abrasive waterjet can cut hard materials; can cut flammable and explosive objects; cutting precision is high, edge is neat no secondary processing is required. Waterjet also has the title of universal cutting machine.
Q: How to choose the cutting table?
A:You need to offer the size of the materials you want to process or the size of the cutting table.
Q:How to solve the incision problem of water cutting?
A:It is not a vertical cutting for a waterjet cutter. This is due to the physical characteristics of waterjet. If it is required precise vertical angle cutting, we will provide you with a five-axis dynamic cutting system.
Q:Is the equipment easy to operate?
A:Wonlean intelligent waterjet cutting machine is easy to operate. You could upload the electronic images file of DXF format to the operating system via USB or network. The system will automatically program, and only need to set a few simple parameters, it can automatically complete the cutting operation.
A :Cold processing, no heat reaction zone. no deformation; strong cutting ability, pure water jet can cut soft materials, abrasive waterjet can cut hard materials; can cut flammable and explosive objects; cutting precision is high, edge is neat no secondary processing is required. Waterjet also has the title of universal cutting machine.
Q: How to choose the cutting table?
A:You need to offer the size of the materials you want to process or the size of the cutting table.
Q:How to solve the incision problem of water cutting?
A:It is not a vertical cutting for a waterjet cutter. This is due to the physical characteristics of waterjet. If it is required precise vertical angle cutting, we will provide you with a five-axis dynamic cutting system.
Q:Is the equipment easy to operate?
A:Wonlean intelligent waterjet cutting machine is easy to operate. You could upload the electronic images file of DXF format to the operating system via USB or network. The system will automatically program, and only need to set a few simple parameters, it can automatically complete the cutting operation.
